Tier 1 brand Risen Solar Panels 580-600Wp solar panels 1000w price

Short Description:

NDS and MBB technologies.enhancing the reliability and durability
Perfectly compatible with main stream optimizers and rapid shut down devices
Cut-cell encapsulation and optimized circuit design,improving 10% module power output
Lower BOS cost and LCOE
Optimal module size and module weight for residential rooftops

Brand Name: RISEN

Model Number: RSM120-8-580-600BMDG

Place of Origin: China

Cell size: 210mmx210mm

Type: PERC, Half Cell, BIPV

Panel Dimensions: 2172*1303*35mm

Panel Efficiency: 21.2%

Certificate: CE TUV IEC

Warranty: 30 years warranty

Rated Power in Watts-Pmax(Wp): 580-600

Maximum Power Current-Impp(A): 17.05-17.25

Maximum Power Voltage-Vmpp(V): 34.04-34.8

Short Circuit Current-Isc(A): 18.06-18.26

Open Circuit Voltage-Voc(V): 40.90-41.70

Superstrate: High Transmission, Low Iron, Tempered ARC Glass

Substrate: Tempered Glass

Frame: Anodized Aluminium Alloy type 6005-2T6, Silver Color

Cables: 4.0mm² (12AWG), Positive(+)350mm, Negative(-)230mm

Send email to us

Product Detail

Alibaba

Product Tags

item	value
Place of Origin	China
Brand Name	RISEN
Model Number	RSM120-8-580-600BMDG
Cell size	210mmx210mm
Type	PERC, Half Cell, BIPV
Panel Dimensions	2172130335mm
Panel Efficiency	21.2%
Certificate	CE TUV IEC
Warranty	30 years warranty
Rated Power in Watts-Pmax(Wp)	580-600
Maximum Power Current-Impp(A)	17.05-17.25
Maximum Power Voltage-Vmpp(V)	34.04-34.8
Short Circuit Current-Isc(A)	18.06-18.26
Open Circuit Voltage-Voc(V)	40.90-41.70
Superstrate	High Transmission, Low Iron, Tempered ARC Glass
Substrate	Tempered Glass
Frame	Anodized Aluminium Alloy type 6005-2T6, Silver Color
Cables	4.0mm² (12AWG), Positive(+)350mm, Negative(-)230mm
